Standard: IEC60269-6
Rated current: 8~35A
Rated voltage: 1500VDC
Size: 10x85mm
Rated breaking capacity: 50kA
Utilization category: gPV
Rated power dissipation: ≤9.3W
Operating temperature: -40°C...+80°C
Certificates: CE, CB, TUV
EKFL15D10L series cylindrical fuse links from ETEK are specifically engineered for the protection of photovoltaic systems requiring high DC voltage ratings. These robust fuses offer exceptional electrical protection with a 1500V DC rating and impressive 50kA breaking capacity, making them ideal for modern solar installations.
Applications:
• Solar photovoltaic systems and arrays
• DC combiner boxes
• PV inverter protection
• Solar charge controllers
• High voltage DC distribution systems
• Utility-scale solar installations
|
Model |
EKFL15D10L |
|
Standard |
IEC60269-6 |
|
Rated voltage |
1500VDC |
|
Rated cureent |
8A~35A |
|
Rated breaking capacity |
50kA |
|
Utilization category |
gPV |
|
Rated power |
no more than 5W at 0.7In |
|
|
no more than 9.3W at 1In |
|
Size |
10mmx85mm |
|
Filling material |
Quartz Sand |
|
Arc voltage limits |
3500V |
|
Operating temperature |
-40°C ... 80°C |
|
Storage temperature |
-40°C ... 90°C |
