Designed for AC circuit protection in solar inverter outputs and auxiliary circuits. Ensures reliable operation in grid-connected systems.
• Ratings from 1A to 125A • Breaking capacity up to 15kA • Temperature compensation
Standard: IEC60947-2
Type of trip: Thermo-magnetic
Rated current: 1~63A
Rated voltage: 230/400V~240/415V
Number of poles: 1P,2P,3P,4P
Rated short-circuit breaking capacity: 15kA
Ambient air temperature: -25...+40 ºC
Connection: From top and bottom
Standard: IEC60898-1&IEC60947-2
Type of trip: Thermo-magnetic
Rated current: 1~63A
Rated voltage: 230/400V~240/415V
Number of poles: 1P,2P,3P,4P
Rated short-circuit breaking capacity: 10kA
Tripping curve: B, C, D
Ambient air temperature: -25...+40 ºC
Connection: From top and bottom
Standard: IEC60898-1，IEC60947-2
Type of trip: Thermo-magnetic
Rated current: 1~63A
Rated voltage: 230/400V~240/415V
Number of poles: 1P,2P,3P,4P
Rated short-circuit breaking capacity: 6kA
Tripping curve: B, C, D
Ambient air temperature: -25...+40 ºC
Connection: From top and bottom
